The Orion™ KRADP series of vacuum pumps are used in the industrial arena where large amounts of flow are needed to run your industrial equipment. These pumps can produce independent vacuum and pressure levels from a single source. They are used where large amounts of vacuum and/or pressure are needed to run robotics, vacuum conveyors, laminators, printing presses, feeders, etc.
These pumps are capable of producing vacuum levels of up to 25 inches of mercury. The Orion™ KRADP Series of pumps can produce well over 150 CFM of vacuum and pressure.
Orion KRX-3 Vacuum and Pressure Specifications
| Model | Motor | RPM | HP | CFM | Max. Hg" | Max. PSI | LBs | KGs |
|---|---|---|---|---|---|---|---|---|
| KRX3-SS | No Motor | 7.4 | 25.0" | 8.5 psig | 46.3 | 21 | ||
| KRX3-SS | 208-230/460V | 1750 | 0.5 | 7.4 | 25.0" | 8.5 psig | 46.3 | 21 |
Performance Specifications
External Dimensions
| H | D | W | A | B | C | E | F | G |
| 248 | 270 | 468 | Ø144 | 80 | 135 | 42 | 177 | 50 |
| I | J | K | L | M | N | O | P | Q |
| 208 | 176 | 32 | 0 | 304 | 364 | 30 | 76.5 | 210.5 |
| R | S | T | U | V | X | Y | Z | |
| 71 | 78 | 154 | 90 | 205 | 230 | 4.5 | 4-Ø9 |
Note: Dimensions in mm
Orion KRX-3 Part Breakdown
| # | Part | Part Number | Quantity |
|---|---|---|---|
| 1 | Vacuum Regulator | 03039289010/JVP-1001-00024 | 1 |
| 2 | Pressure Regulator | 03039289010/JVP-1001-00023 | 1 |
| 3 | Pressure Gauge | 04002320010/JVP-ALL-00037/38 | 1 |
| 4 | Vacuum Gauge | 04002320010/JVP-ALL-00037/38 | 1 |
| *5 | SDX Case Complete | Contact | 1 |
| 6 | Manifold Bolt | Contact | 2 |
| 7a | Manifold Cap (v) | 03039287020 | 2 |
| 7b | Manifold Cap (p) | 03039287010 | 2 |
| 8 | Manifold Cap Gasket | 03039292010 | 2 |
| 9 | SDX Case | 01031013010 | 1 |
| 10 | Plug | 04039361010/HexPlug-JVP-3/5/6 | |
| 11 | Filter Rod | 04039360040 | 2 |
| 12 | Filter | 04000028010/JVP-1001-00027 | 2 |
| 13 | Spring Tube | 04039359010/JVP-1001-00029V | 2 |
| 14 | Filter Gasket | 03039263010 | 2 |
| 15 | Filter Case KRX-3 | 03039259010 | 1 |
| 16 | Gasket Washer | 04000695010/JVP-1001-00033A | 2 |
| 17 | Knob | 04034947010/JVP-1001-00033 | 2 |
| 18 | Muffler Cover | 03039260010 | 1 |
| 19 | Pump Only KRX-3 | Contact | 1 |
| 20 | Manifold Gasket | 04009579010/JVP-1001-00013 | 1 |
| 21 | Fan Housing Guard | 03039901010 | 1 |
| 22 | Fan | 02034550010 | 1 |
| 23 | Bearing Cover | 04009352010/JVP-3-00009 | 2 |
| 24 | Liner/Shim | JVP-3-00010 | 10 |
| 25 | Bearing | 039001116220/JVP-3-00006 | 2 |
| 26 | Bearing Spacer | 04009353010/JVP-3-00007 | 2 |
| 27 | Side Plate F.S. | 03039266010 | 1 |
| 28 | Taper Pin | 033611111300 | 4 |
| 29 | Rotor | 03039273010 | 1 |
| 30 | Key | 033300412000/JVP-1001-00015 | 1 |
| 31 | Vane/Blade | 04009564010/JVP-3-00003 | 4 |
| 32 | Pump Housing KRX-3 | 02034516010 | 1 |
| 33 | Side Plate M.S. | 03039267010 | 1 |
| 34 | Pump Side Coupling | 04034905010 | 1 |
| 35 | Spider | 04002338010 | 1 |
| 36 | Motor Side Coupling | 04034905020 | 1 |
| 37 | Motor | Contact | 1 |
| 38 | Coupling Guard | 03036521010 | 1 |
| 39 | Base | Contact | 1 |
Download Part Breakdown PDF
Product Manual
Orion KRX-3 Rebuild Kit Part List
| Description | Product ID | Quantity |
|---|---|---|
| Filters | JVP-1001-00027-A | 2 |
| Spring Tube, new style, Filter-side | JVP-1001-00029V | 1 |
| Rubber Gaskets for Filter Case and Muffler cover | 03039263010 | 2 |
| Washer Gaskets for Filter Knobnut | JVP-1001-00033A | 2 |
| Manifold Gasket | JVP-1001-00013 | 1 |
| Shims | JVP-3-00010 | 10 |
| Bearings | JVP-3-00006 | 2 |
| Bearing Spacers | JVP-3-00007 | 2 |
| Vanes | JVP-3-00003 | 4 |
| Spider Flexible Coupling | 04002338010 | 1 |
